Ford YT12.5, YT14, YT16, YT16H, YT18H Tractor Service Manual

Covers: Ford YT12.5 YT14 YT16 YT16H YT18H Yard Tractors
Pages: 131
Format: PDF
File size: 9mb
Compatible with: Windows/Mac/Tablet/Smartphone

Get the original Ford YT12.5, YT14, YT16, YT16H and YT18H tractor service manual in a clear PDF format, instantly! This downloadable guide is dated September 1994 and covers troubleshooting and repair work on the chassis. Whether you’re a hands-on tractor owner, mechanic, or repair shop, you’ll have access to the exact same information used by Ford dealer techs. From simple checks and adjustments to component replacement, OEM specifications, procedures and illustrations following the exact requirements from the manufacturer are included to get the job done efficiently and safely.

Please note that B&S and Kohler engine repair manuals are sold separately.

Model numbers covered: 09GN2151, 09GN2152, 09GN2153, 09GN2154, 09GN2155, 09GN2198, 09GN2199, 9607430, 9607431, 9607432, 9607481, 9607482, 9800686, 9800687, 9800688, 9801250, 9809209

Don’t let long shipping times stop your weekend project. A download link will be emailed to you within just a few minutes. The PDF can be viewed on your computer, tablet, or smartphone from the shop or in the yard.

Topics:

INTRODUCTION AND SAFETY

LUBRICATION AND MAINTENANCE

ADJUSTMENTS AND SERVICING

• Engine Remove & Replace
• Electric PTO Clutch/Brake
• Adjustment
• Clutch Coil Check
• Remove & Replace
• Fuel Tank Remove & Replace
• Transaxle
• Transaxle Remove & Replace
• Traction Drive Brake Adjustment
• Brake Pad Replacement.
• Traction Drive Belt
• Belt Adjustment
• Belt Remove & Replace
• Front Axle Remove & Replace
• Steering Shaft Removal
• Steering Gear Adjustment
• Steering Sector Removal
• Clutch/Brake Foot Pedal Removal
• Clutch Pivot Bracket Removal
• Traction Drive Gear Shift
• Lever Adjustment (Models 09GN2151 & 09GN2152 only)
• Traction Drive Gear Shift
• Attachment Lift Lever Shaft Removal
• Throttle Control Lever Removal
• Choke Cable Removal
• Electrical System
• System Functions
• Battery
• Solenoid Check
• Ammeter Check
• Ignition Switch Check
• Interlock Switch System Check
• Headlight Switch Check
• Headlight Replacement
• Fuse Replacement
• P.T.O. Warning Light Check
• Wiring Diagrams

TROUBLESHOOTING

BOLT TORQUE SPECIFICATIONS
